Manufacturer: Relpol
€7.27€8.80
Unit price, excl. VAT (€8.80 incl. VAT)Unit price, incl. VAT (€7.27 excl. VAT)
€5.68 – €8.76 excl. VAT€6.87 – €10.60 incl. VAT
| Part number | Contacts | Coil voltage | Protection category | Packaging | Unit priceexcl. VAT (incl. VAT)incl. VAT (excl. VAT) |
|---|---|---|---|---|---|
| RM83-3011-25-1005 | — | 5 V DC | IP 40 | 50 | €7.27(€8.80)€8.80(€7.27) |
| RM83-3011-25-1005-01 | 1 CO | 5 V DC | IP 40 | 50 | €7.72(€9.34)€9.34(€7.72) |
| RM83-3011-25-1009 | 1 CO | 9 V DC | IP 40 | 50 | €7.72(€9.34)€9.34(€7.72) |
| RM83-3011-25-1012 | 1 CO | 12 V DC | IP 40 | 50 | €8.24(€9.97)€9.97(€8.24) |
| RM83-3011-25-1012-01 | 1 CO | 12 V DC | IP 40 | 50 | €8.76(€10.60)€10.60(€8.76) |
| RM83-3011-35-1012 | 1 CO | 12 V DC | IP 40 | 50 | €8.20(€9.92)€9.92(€8.20) |
| RM83-3011-25-1024 | 1 CO | 24 V DC | IP 40 | 50 | €8.41(€10.18)€10.18(€8.41) |
| RM83-3011-25-1024-01 | 1 CO | 24 V DC | IP 40 | 50 | €7.72(€9.34)€9.34(€7.72) |
| RM83-3011-35-1024 | 1 CO | 24 V DC | IP 40 | 50 | €8.40(€10.16)€10.16(€8.40) |
| RM83-3011-25-1048 | 1 CO | 48 V DC | IP 40 | 50 | €7.65(€9.26)€9.26(€7.65) |
| RM83-3011-25-1110 | 1 CO | 110 V DC | IP 40 | 50 | €8.11(€9.81)€9.81(€8.11) |
| RM83-3021-25-1005 | 1 NO | 5 V DC | IP 40 | 50 | €6.18(€7.48)€7.48(€6.18) |
| RM83-3021-25-1005-01 | 1 NO | 5 V DC | IP 40 | 50 | €5.68(€6.87)€6.87(€5.68) |
| RM83-3021-25-1012 | 1 NO | 12 V DC | IP 40 | 50 | €7.16(€8.66)€8.66(€7.16) |
| RM83-3021-25-1012-01 | 1 NO | 12 V DC | IP 40 | 50 | €5.68(€6.87)€6.87(€5.68) |
| RM83-3021-35-1012 | 1 NO | 12 V DC | IP 67 | 50 | €6.99(€8.46)€8.46(€6.99) |
| RM83-3021-25-1024 | 1 NO | 24 V DC | IP 40 | 50 | €6.43(€7.78)€7.78(€6.43) |
| RM83-3021-25-1024-01 | 1 NO | 24 V DC | IP 40 | 50 | €5.68(€6.87)€6.87(€5.68) |
| RM83-3021-35-1024 | 1 NO | 24 V DC | IP 67 | 50 | €6.43(€7.78)€7.78(€6.43) |
| RM83-3021-25-1048 | 1 NO | 48 V DC | IP 40 | 50 | €6.48(€7.84)€7.84(€6.48) |
| RM83-3021-25-1060 | 1 NO | 60 V DC | IP 40 | 50 | €5.68(€6.87)€6.87(€5.68) |
| RM83-3021-25-1110 | 1 NO | 110 V DC | IP 40 | 50 | €6.30(€7.62)€7.62(€6.30) |
| RM83-3021-25-S110 | 1 NO | 110 V DC sensitive coil | IP 40 | 50 | €6.54(€7.91)€7.91(€6.54) |
Prices per piece, excl. or incl. 21% VAT as chosen, with the other in brackets. Ask us for volume pricing and lead times. Terms & policies
Miniature relays RM83-3011-25-1005. Contact material: AgSnO2. Voltage coil 5 V DC. Rated load AC1 16 A / 250 V AC. Mounting: for PCB and sockets. Cover protection category IP 40.
