PI84T-024DC-M41G-TS-3012-V0

PI railway – Relays for railroad industry

Manufacturer: Relpol

€16.50€19.97

Unit price, excl. VAT (€19.97 incl. VAT)Unit price, incl. VAT (€16.50 excl. VAT)

€16.50 – €19.28 excl. VAT€19.97 – €23.33 incl. VAT

Contacts: 2 CO

Coil voltage: 24 V DC

Request Quote & Pricing

Download Documentation

Packaging:: 10

Pricing

4 variants

Part number	Contacts	Coil voltage	Packaging	Unit priceexcl. VAT (incl. VAT)incl. VAT (excl. VAT)
PI84T-024DC-M41G-TS-3012-V0	2 CO	24 V DC	10	€16.50(€19.97)€19.97(€16.50)
PI84T-110DC-M43G-TS-3012-V0	2 CO	110 V DC	10	€16.50(€19.97)€19.97(€16.50)
PI85T-024DC-M41G-TS-3011-V0	1 CO	24 V DC	10	€19.28(€23.33)€23.33(€19.28)
PI85T-110DC-M43G-TS-3011-V0	1 CO	110 V DC	10	€17.60(€21.30)€21.30(€17.60)

Prices per piece, excl. or incl. 21% VAT as chosen, with the other in brackets. Ask us for volume pricing and lead times. Terms & policies

Specification

Relays for railroad industry - interface PI84T-024DC-M41G-TS-3012-V0, 2 CO. Contact material: AgSnO2. Voltage coil 24 V DC. Rated load AC1 8 A / 250 V AC. Mounting: mounting on 35 mm rail. Cover protection category IP 20.

Part number: PI84T-024DC-M41G-TS-3012-V0
Contact material: AgSnO2
Protection category: IP 20
Dimensions (D × W × H): 80 × 15.6 × 61 mm
Mounting: mounting on 35 mm rail
Rated switching voltage: 250 V AC
Operating temperature: -40…+55
Contacts: 2 CO
Coil voltage: 24 V DC
Rated load AC1: 8 A / 250 V AC
Rated load DC1: 8 A / 24 V DC
Motor load AC3: 0,37 kW
Packaging: 10
Weight: 0.061 kg
Customs tariff code: 85364190
